Hikmicro Lynx LH15 3.0 – Thermal Monocular | EOFY SALE
$1,529.10
FOR EXPERT ADVICE, PRICE MATCHING OR BUNDLES 0427312312
5 in stock
Hikmicro Lynx 3.0 LH15 Thermal Monocular
The LH15 3.0 is a top choice for your first 20mK thermal monocular. Equipped with a 320×240 detector and a free-focus 15mm F1.0 lens, it offers a 2.2x base magnification with an 11.7° field of view and a detection range of 750m. With its compact design and superb image quality, it is perfect for forest environments and mid-range applications.
Remark：
1. The shutter module has been retained to ensure high image quality for power-up and under large temperature variations.
2. The battery time data comes from HIKMICRO lab. The actual result may differ due to the environment and personal usage habits. Please refer to actual experience.
3. The HIKMICRO Sight APP connection process complies with the latest CE RED Directive (2014/53/EU) and the EN 18031 standard. We are always your most reliable choice.
*All the pictures and videos taken by device are for reference only, the actual effect shall prevail.
*All images, videos, and screen display contents about the product itself on this page are for reference only. Actual product effects (including but not limited to appearance, color, and size) and screen display contents (including but not limited to backgrounds, UI, and illustrations) may vary.
| SPECIFICATION | |
| Product Model | LH15 3.0 |
| Thermal Module | |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Max. Resolution | 320×240 |
| Frame Rate | 50Hz |
| Pixel Interval | 12μm |
| Response Waveband | 8μm to 14μm |
| NETD | Less than 18 mK (@25°C), F#=1.0 |
| Lens (Focal Length) | 15mm, f1.0 |
| Detection Range | 750m |
| Focus Mode | Focus Free |
| Field of View (H × V), Degrees / m @100m | 11.7°×8.8° / 20.5m × 15.4m |
| Min. Focusing Distance | 7.0m |
| Magnification | 2.2x – 17.6x (8x) |
| Image Display | |
| Display | 1024×768, 0.39 inch, AMOLED |
| Contrast Adjustment | Yes |
| Brightness Adjustment | Yes |
| Palettes | Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome |
| Exit Pupil | 6mm |
| Eye Relief | 20mm |
| Diopter (Range) | -5D to +3D |
| Tone Adjustment | Cold, Warm |
| Zoom Pro | Yes |
| HSIS (HIKMICRO Shutterless Image System) | Yes |
| Image Pro 3.0 | Yes |
| General | |
| Protection Level | IP67 |
| Weight | 296.5 g with battery |
| Dimension | 156.3 × 53.6 × 49.5 mm |
| Working Temperature | From -30°C to 45°C (-22°F to 113°F); Humidity: 90% or Less |
| System | |
| Built-in Memory | Built-in EMMC (64 GB) |
| Record Video | Yes |
| Capture Snapshot | Yes |
| Hotspot | 2.4 GHz / 5 GHz Wi-Fi Waveband |
| Standby Mode | Yes |
| PIP | Yes |
| Hot Track | Yes |
| Distance Measurement | Yes |
| Audio Recording | Yes |
| Local Album | Yes |
| Power Supply | |
| Battery Type | Replaceable and Rechargeable Li-ion 18650 Battery |
| Battery Operating Time | 5.5-hour continuous running with hotspot on (@25°C) 5-hour continuous running with hotspot on (@-20°C) |
| Type-C Power Supply | 5V DC, 2A Supports External Power Supply, Support Direct Charging |
