Pixfra Draco D225-4K – Day & Night Multispectral Binoculars
$1,790.00
Pixfra Draco D225-4K
Introducing the Draco D225-4K multispectral binoculars from Pixfra. Combining the detection capabilities of thermal imaging with the identification capabilities of digital night vision and 4K day optics, whilst also offering the ability to gauge accurate distance measurements via a built-in laser rangefinder, this intuitive pair of binoculars will provide an all-in-one observation solution. 4K UHD night vision, along with AI powered processing and exclusive Wizcolour technology, achieves next-level image clarity, delivering sharp images in low-light conditions. Plus, enhanced night vision sensitivity ensures every detail is visible in near-total darkness.
PRODUCT PARAMETERS
| Product Model | D225-4K | D225N-4K | D335-4K | D335N-4K | D635-4K | D635N-4K |
| Detector Type | Vanadium oxide uncooled focal plane detector |
Vanadium oxide uncooled focal plane detector |
Vanadium oxide uncooled focal plane detector |
Vanadium oxide uncooled focal plane detector |
Vanadium oxide uncooled focal plane detector |
Vanadium oxide uncooled focal plane detector |
| Effective Pixels | 256 (H) ×192 (V) | 256 (H) ×192 (V) | 384 (H) × 288 (V) | 384 (H) × 288 (V) | 640 (H) × 512 (V) | 640 (H) × 512 (V) |
| Pixel Pitch | 12 μm | 12 μm | 12 μm | 12 μm | 12 μm | 12 μm |
| Spectral Range | 8μm～14μm | 8μm～14μm | 8μm～14μm | 8μm～14μm | 8μm～14μm | 8μm～14μm |
| Sensitivity (NETD) | ≤18 mK@f/1.0 | ≤18 mK@f/1.0 | ≤15 mK@f/1.0 | ≤15 mK@f/1.0 | ≤15 mK@f/1.0 | ≤15 mK@f/1.0 |
| Focal Length | 25 mm | 25 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Aperture | F0.9 | F0.9 | F0.95 | F0.95 | F1.0 | F1.0 |
| Focus Control | Manual | Manual | Manual | Manual | Manual | Manual |
| Field of View | H: 7.0°; V: 5.3°/H: 12.2 m; V: 9.3 m (@100 m) |
H: 7.0°; V: 5.3°/H: 12.2 m; V: 9.3 m (@100 m) |
H: 7.5°; V: 5.6°/H: 13.7 m; V: 10.3 m (@100 m) |
H: 7.5°; V: 5.6°/H: 13.7 m; V: 10.3 m (@100 m) |
H: 12.52°; V: 10.0°/H: 21.9 m; V: 17.6 m (@100 m) |
H: 12.52°; V: 10.0°/H: 21.9 m; V: 17.6 m (@100 m) |
| Detection Distance | 1,300 m (4,5265.09 ff) |
1,300 m (4,5265.09 ff) |
1,800 m (5,905.51 ff) |
1,800 m (5,905.51 ff) |
1,800 m (5,905.51 ff) |
1,800 m (5,905.51 ff) |
| Close Focus Distance | 3 m | 3 m | 3 m | 3 m | 3 m | 3 m |
| Digital Zoom | 1×–8× | 1×–8× | 1×–8× | 1×–8× | 1×–8× | 1×–8× |
| Base Magnification | 4.3× | 4.3× | 3.8× | 3.8× | 2.5× | 2.5× |
| Max. Resolution | 3840 (H) × 2160 (V) | 3840 (H) × 2160 (V) | 3840 (H) × 2160 (V) | 3840 (H) × 2160 (V) | 3840 (H) × 2160 (V) | 3840 (H) × 2160 (V) |
| Frame Rate | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz |
| Focal Length | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Aperture | F2.0 | F2.0 | F2.0 | F2.0 | F2.0 | F2.0 |
| Field of View | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) | H: 8.0°; V: 4.5°/H: 14.0 m; V: 8.8 m (@100 m) |
| Focal Length | Manual | Manual | Manual | Manual | Manual | Manual |
| Close Focus Distance | 7 m | 7 m | 7 m | 7 m | 7 m | 7 m |
| Base Magnification | 5.5× | 5.5× | 5.5× | 5.5× | 5.5× | 5.5× |
| Digital Zoom | 1×–8× | 1×–8× | 1×–8× | 1×–8× | 1×–8× | 1×–8× |
| Screen Size | 1920 × 1080, 0.49 inch, OLED |
1920 × 1080, 0.49 inch, OLED |
1920 × 1080, 0.49 inch, OLED |
1920 × 1080, 0.49 inch, OLED |
1920 × 1080, 0.49 inch, OLED |
1920 × 1080, 0.49 inch, OLED |
| Color Palettes | Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
Thermal: White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia Digital: Colour, Black White, Green, Yellow, Auto |
| Interpupillary Adjustment | 60 mm–74 mm | 60 mm–74 mm | 60 mm–74 mm | 60 mm–74 mm | 60 mm–74 mm | 60 mm–74 mm |
| Image Modes | Thermal/Visible/PIP | Thermal/Visible/PIP | Thermal/Visible/PIP | Thermal/Visible/PIP | Thermal/Visible/PIP | Thermal/Visible/PIP |
| Video Recorder | Yes | Yes | Yes | Yes | Yes | Yes |
| Snapshot | Yes | Yes | Yes | Yes | Yes | Yes |
| Wi-Fi Hotspot | Yes | Yes | Yes | Yes | Yes | Yes |
| Hot Spot Track | Yes | Yes | Yes | Yes | Yes | Yes |
| FFC (Flat Field Correction) Mode | Auto; Semi-Auto; Manual | Auto; Semi-Auto; Manual | Auto; Semi-Auto; Manual | Auto; Semi-Auto; Manual | Auto; Semi-Auto; Manual | Auto; Semi-Auto; Manual |
| Standby Mode | Yes | Yes | Yes | Yes | Yes | Yes |
| DPC (Defective Pixel Correction) | Yes | Yes | Yes | Yes | Yes | Yes |
| MIC | Yes | Yes | Yes | Yes | Yes | Yes |
| Compass | Yes | Yes | Yes | Yes | Yes | Yes |
| PIP | Yes | Yes | Yes | Yes | Yes | Yes |
| GPS | Yes | Yes | Yes | Yes | Yes | Yes |
| Local Album | Yes | Yes | Yes | Yes | Yes | Yes |
| Storage | Built-in 64 GB | Built-in 64 GB | Built-in 64 GB | Built-in 64 GB | Built-in 64 GB | Built-in 64 GB |
| PIPS 3.0 | Yes | Yes | Yes | Yes | Yes | Yes |
| Smart IR | Yes | Yes | Yes | Yes | Yes | Yes |
| IR Illuminator Wavelength | 850 nm | 940 nm | 850 nm | 940 nm | 850 nm | 940 nm |
| IR Illuminator Range | 400 m (1,312.34 ft) | 350 m (1,148.29 ft) | 400 m (1,312.34 ft) | 350 m (1,148.29 ft) | 400 m (1,312.34 ft) | 350 m (1,148.29 ft) |
| Replaceable IR Illuminator | Yes | Yes | Yes | Yes | Yes | Yes |
| Laser Range | 1,000 m | 1,000 m | 1,000 m | 1,000 m | 1,000 m | 1,000 m |
| Laser Accuracy | ±1 m | ±1 m | ±1 m | ±1 m | ±1 m | ±1 m |
| Laser Safety | Class 1 | Class 1 | Class 1 | Class 1 | Class 1 | Class 1 |
| Battery Type | Replaceable 18650 Lithium battery |
Replaceable 18650 Lithium battery |
Replaceable 18650 Lithium battery |
Replaceable 18650 Lithium battery |
Replaceable 18650 Lithium battery |
Replaceable 18650 Lithium battery |
| Battery Operating Time | ≥9 h@25 °C (Wi-Fi off) | ≥9 h@25 °C (Wi-Fi off) | ≥8 h@25 °C (Wi-Fi off) | ≥8 h@25 °C (Wi-Fi off) | ≥8 h@25 °C (Wi-Fi off) | ≥8 h@25 °C (Wi-Fi off) |
| Power Supply | 5 VDC | 5 VDC | 5 VDC | 5 VDC | 5 VDC | 5 VDC |
| USB | USB Type-C | USB Type-C | USB Type-C | USB Type-C | USB Type-C | USB Type-C |
| Operating Temperature | −30 °C to +55 °C (−22 °F to +131 °F) |
−30 °C to +55 °C (−22 °F to +131 °F) |
−30 °C to +55 °C (−22 °F to +131 °F) |
−30 °C to +55 °C (−22 °F to +131 °F) |
−30 °C to +55 °C (−22 °F to +131 °F) |
−30 °C to +55 °C (−22 °F to +131 °F) |
| Protection Grade | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
| Product Dimensions | 195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
195.0 mm × 130.6 mm × 61.7 mm (7.68″ × 5.14″ × 2.43″) (L × W × H) |
| Packaging Dimensions | 286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
286.0 mm × 228.0mm × 107.0 mm (11.26″ × 8.98″ × 4.21″) (L × W × H) |
| Net Weight | ≤0.61 kg (1.34 lb) | ≤0.61 kg (1.34 lb) | ≤0.62 kg (1.37 lb) | ≤0.62 kg (1.37 lb) | ≤0.62 kg (1.37 lb) | ≤0.62 kg (1.37 lb) |
